Titanium Bolts & Screws

Metric Titanium Bolts & Screws Standard:  DIN, JIS, ISO, BS
Inch  Titanium Bolts & Screws Standard:  ANSI/ASME B18.3, ANSI/ASME B18.2.1
The Popular Inch Bolts & Screws size : 1/4”  ,3/8”, 7/6”  ,3/4”  7/8”  5/8”.

Material: Gr1, Gr2, Gr5,Gr7, Gr9, Gr12
Material Standard: AMS4928/4967, ASTM 348 ,Special demand(Tensile stregnth more than1100Mpa)

Non-standard and special size is available according to your drawing or requirement
Big Inventory of  Titanium Gr2  Gr5  DIN933 DIN912 DIN7991  DIN6921 Bolts and Screws

Our advantage

1)Aerospace Grade Titanium round bars as raw material

2) Fast shipment : Within 7 days

3) 100% Quality control throughout traceability

4) 15 years Experience in manufacturing Titanium Bolts & Screws

5) Technical Service : Your Titanium Expert with One Stop Solution



Product Details





1. The Applications of Titanium Bolts & Screws.

Xi'an Ocean Trading Co., Ltd.



Ti6Al4V Bolts & Screws in Submarine  Engineering

Titanium's low temperature properties and excellent corrosion resistance are preferred in deep submersibles, submarine sinking equipment, subsea exploration equipment and shipbuilding.

Xi'an Ocean Trading Co., Ltd.



C.P. Titanium Bolts & Screws in Oil & Gas Pipeline

The corrosion resistance of titanium, and pipeline pressure effect is excellent, the strength can reach the level 8.8, and 10.9, the weight is only 57% of the same steel screws, service life is long, generally in the pipe connection with titanium flange and fittings.







Xi'an Ocean Trading Co., Ltd.

CP.Titanium Bolts & Screws in High Pressure Vessel

Due to the excellent corrosion resistance of titaniumbolts, it is widely used in electroplating equipment, distillers, heat exchangers, condensing towers and Reaction valvetowers and numerous chemical equipments.





Parameters


2.The main Specifications and Stock dimensions


Specification :Gr2 DIN933/931 Hexagon Head Bolts

Size :M5*15/M6*20/M8*25/M10*30



Specification :Gr5 DIN912 Hexagon Socket Head Cap Screws

Specification :Gr5 DIN912 Tap Hexagon Socket Tapered Head Cap Screws

Size :M5*18/M6*30/M8*40/M10*25/ M3*20





Specification :Gr5 ISO7380  Hexagon Socket Button Head Screws (Torx)

Size :M3/M4/M5/M6/M8/M10





Specification :Gr5 DIN6921  Hexagon Flange Bolts

Size :M5/M6/M8/M10/M12





Specification :Gr5/Gr2  DIN7991 Socket Countersunk Head Cap Screws

Size :M5/M6/M8/M10
